The FF5507 is a high-performance spin-on secondary fuel filter manufactured by Fleetguard. It is widely used in heavy-duty trucks and tractors to trap fine particulate contaminants and protect sensitive high-pressure common-rail and unit-injector diesel fuel systems.
Micron Rating: 5 microns at 98% efficiency (SAE J 1858).
Thread Size: M32 X 1.5-6H INT.
Overall Height / Length: 263.91 mm (10.39 inches).
Largest Outer Diameter: 107.67 mm (4.24 inches).
Gasket Inside Diameter: 90.55 mm (3.56 inches).
Gasket Outer Diameter: 99.95 mm (3.93 inches).
Cross-Reference Numbers:
Baldwin: BF7814
Donaldson: P550529 or P550739
Wix: 33721
Luber-finer: LFF8059
Fram: P9626
Volvo/Mack OEM: 20430751, 20972295
The FF5507 is a high-performance spin-on secondary fuel filter manufactured by Fleetguard. It is widely used in heavy-duty trucks and tractors to trap fine particulate contaminants and protect sensitive high-pressure common-rail and unit-injector diesel fuel systems.
Micron Rating: 5 microns at 98% efficiency (SAE J 1858).
Thread Size: M32 X 1.5-6H INT.
Overall Height / Length: 263.91 mm (10.39 inches).
Largest Outer Diameter: 107.67 mm (4.24 inches).
Gasket Inside Diameter: 90.55 mm (3.56 inches).
Gasket Outer Diameter: 99.95 mm (3.93 inches).
Cross-Reference Numbers:
Baldwin: BF7814
Donaldson: P550529 or P550739
Wix: 33721
Luber-finer: LFF8059
Fram: P9626
Volvo/Mack OEM: 20430751, 20972295
