The 3600AX brake drum is a severe-duty, outboard-mount balanced brake drum widely utilized on heavy-duty commercial truck rear axles and semi-trailers. It is a Demodog manufactured as a standard industry pattern by Premier Wheel End and is compatible with major truck lines, including Freightliner, Volvo, Peterbilt, Kenworth, Mack, etc.
Brake Size: 16.5" x 7"
Mounting Type: Outboard
Bolt Holes: 10 holes, sized at 1.00" diameter
Bolt Circle Diameter: 11.25"
Pilot Diameter: 8.78"
Overall Depth: 10.56"
Maximum Wear Diameter: 16.62"
Average Weight: 110 lbs
The 3600AX brake drum is a severe-duty, outboard-mount balanced brake drum widely utilized on heavy-duty commercial truck rear axles and semi-trailers. It is a Demodog manufactured as a standard industry pattern by Premier Wheel End and is compatible with major truck lines, including Freightliner, Volvo, Peterbilt, Kenworth, Mack, etc.
Brake Size: 16.5" x 7"
Mounting Type: Outboard
Bolt Holes: 10 holes, sized at 1.00" diameter
Bolt Circle Diameter: 11.25"
Pilot Diameter: 8.78"
Overall Depth: 10.56"
Maximum Wear Diameter: 16.62"
Average Weight: 110 lbs
